NbSe2 (Niobium Diselenide) Sputtering Targets

  • High Purity: ≥99.5% purity to ensure high-quality thin-film deposition.
  • Unique Layered Structure: Facilitates superior electronic and optical properties for advanced applications.
  • Superconducting Properties: Ideal for applications in superconducting electronics and quantum computing research.
  • High Stability: Reliable performance under sputtering conditions with excellent chemical stability.
  • Customizable: Tailored sizes and shapes for different deposition setups.

Custom products or bulk orders, please contact us for competitive pricing!

  • Done Satisfaction Guaranteed
  • Done No Hassle Refunds
  • Done Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal

Description

Material Niobium Diselenide (NbSe₂)
Purity 99.5% – 99.9999% / 2N5 3N 3N5 4N 4N5 5N 5N5 6N
Shape disc, plate, sheet, rod, customized
Size can be customized (contact us)
Package vacuum bag or customer’s request
MOQ 1pcs
Supply Ability 10000pcs per month
Lead Time Qty: 1-100, Time: 3-10 days

Qty: >100, Time: to be negotiated



Niobium Diselenide (NbSe₂) sputtering targets are high-quality materials used in the production of thin films for advanced applications in electronics, optoelectronics, and energy devices. Known for their unique layered structure, these targets offer exceptional electrical and optical properties, making them ideal for use in semiconductors, superconductors, and 2D materials research.

Key Applications

  • Superconducting Thin Films: Used in research and development of high-temperature superconductors.
  • Optoelectronic Devices: Ideal for devices requiring high-performance electronic properties.
  • Semiconductor Devices: Thin films for microelectronics and integrated circuits.
  • 2D Materials Research: For exploring the properties of 2D layered materials in various technological innovations.

Features and Benefits

  • High Purity: ≥99.5% purity to ensure high-quality thin-film deposition.
  • Unique Layered Structure: Facilitates superior electronic and optical properties for advanced applications.
  • Superconducting Properties: Ideal for applications in superconducting electronics and quantum computing research.
  • High Stability: Reliable performance under sputtering conditions with excellent chemical stability.
  • Customizable: Tailored sizes and shapes for different deposition setups.

Specifications

  • Purity: ≥99.5%.
  • Density: Approx. 6.1 g/cm³.
  • Shapes Available: Circular, rectangular, or custom configurations.
  • Sizes: Custom sizes available to fit sputtering systems.
  • Surface Finish: Polished for uniform thin-film deposition.

Customization Options

  • Shapes and Sizes: Customizable to meet your specific sputtering system and application needs.
  • Purity: Higher purity grades available for specialized applications.
  • Backing Plate Options: Choose from various backing plate materials for enhanced thermal conductivity.

For high-performance Niobium Diselenide (NbSe₂) sputtering targets, contact us today. Our experts can assist with customized solutions, ensuring your thin-film deposition process meets the highest standards for your application.
