PbS (Lead Sulfide) Pellets Granules Evaporation Materials

  • Narrow Bandgap: PbS has a small bandgap (~0.37 eV), allowing it to detect and respond to IR radiation, making it ideal for infrared applications.
  • High Infrared Sensitivity: PbS thin films exhibit excellent sensitivity to infrared light, especially in the mid-IR range, enhancing performance in IR detectors and sensors.
  • Efficient Light Absorption: PbS absorbs light efficiently, making it a great material for photovoltaic devices and optoelectronic components.
  • Good Thermal Stability: PbS films maintain their properties under moderate temperature conditions, suitable for use in thermal and IR-sensitive devices.
  • Adaptability to Thin Films: PbS can be easily deposited as a thin film via evaporation, making it suitable for creating highly sensitive IR detectors and optical coatings.

Custom products or bulk orders, please contact us for competitive pricing!

  • Done Satisfaction Guaranteed
  • Done No Hassle Refunds
  • Done Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal

Description

Material Lead Sulfide (PbS)
Purity 99.9% – 99.9999% / 3N 3N5 4N 4N5 5N 5N5 6N
Shape Pellets / Granules / Particles / Pieces
Size can be customized (contact us)
Package vacuum bag or customer’s request
Place of Origin China
Supply Ability 1000kg per month
Lead Time Qty: 1-100, Time: 3-10 days

Qty: >100, Time: to be negotiated



PbS (Lead Sulfide) pellets are a common material used for physical vapor deposition (PVD) techniques such as thermal and electron-beam evaporation to produce thin films. PbS is a narrow bandgap semiconductor with excellent infrared (IR) detection capabilities, making it highly useful in IR detectors, photovoltaics, and optoelectronic devices.

Key Applications:

  • Infrared Detectors: PbS is widely used in IR sensors and detectors, particularly in the mid-infrared region (1-3 µm). It is sensitive to IR radiation, making it useful for applications like thermal imaging, spectroscopy, and gas sensing.
  • Photovoltaics: PbS thin films are used in solar cells and photodetectors due to their strong light absorption and narrow bandgap properties, which allow efficient light-to-electricity conversion.
  • Optoelectronics: PbS is utilized in optoelectronic devices such as infrared light-emitting diodes (LEDs) and lasers.
  • Thermal Imaging: PbS coatings are applied in thermal imaging systems for military, aerospace, and industrial applications.

Features:

  • Narrow Bandgap: PbS has a small bandgap (~0.37 eV), allowing it to detect and respond to IR radiation, making it ideal for infrared applications.
  • High Infrared Sensitivity: PbS thin films exhibit excellent sensitivity to infrared light, especially in the mid-IR range, enhancing performance in IR detectors and sensors.
  • Efficient Light Absorption: PbS absorbs light efficiently, making it a great material for photovoltaic devices and optoelectronic components.
  • Good Thermal Stability: PbS films maintain their properties under moderate temperature conditions, suitable for use in thermal and IR-sensitive devices.
  • Adaptability to Thin Films: PbS can be easily deposited as a thin film via evaporation, making it suitable for creating highly sensitive IR detectors and optical coatings.

Specifications:

  • Material: Lead Sulfide (PbS)
  • Purity: ≥ 99.9%
  • Shape: Pellets
  • Size: Typically 1-6 mm diameter, custom sizes available
  • Density: 7.6 g/cm³
  • Melting Point: 1,118°C
  • Deposition Methods: Suitable for thermal evaporation, electron-beam evaporation, and sputtering
  • Bandgap: ~0.37 eV (semiconducting)
  • Electrical Conductivity: Low, ideal for use in infrared detectors and semiconductor devices
  • Optical Properties: Strong absorption in the infrared region, highly effective for IR-sensitive coatings and applications
  • Applications: Infrared detectors, thermal imaging, photovoltaic devices, optoelectronic sensors, and IR LEDs.

Tinsan Materials offers PbS (Lead Sulfide) evaporation pellets for thin film deposition. Used in IR detectors, photovoltaics, and optoelectronics. High-purity PbS for thermal and e-beam evaporation processes.

If you have specific requirements, such as dimensions, purity, or application details, please contact us to match your needs.
