SnS (Tin Sulfide) Pellets Granules Evaporation Materials
- High purity (≥99.99%).
- Outstanding semiconducting properties with a direct bandgap.
- Suitable for thin-film deposition methods like PVD and CVD.
- Excellent stability under high-temperature and chemical conditions.
- Customizable sizes and packaging options available.
Custom products or bulk orders, please contact us for competitive pricing!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
Material | Tin Sulfide (SnS) |
Purity | 99.9% – 99.9999% / 3N 3N5 4N 4N5 5N 5N5 6N |
Shape | Pellets / Granules / Particles / Pieces |
Size | can be customized (contact us) |
Package | vacuum bag or customer’s request |
Supply Ability | 1000kg per month |
Lead Time | Qty: 1-100, Time: 3-10 days
Qty: >100, Time: to be negotiated |
SnS Pellets (Tin Sulfide Pellets) are high-purity semiconductor materials widely used in optoelectronics, energy conversion, and thin-film deposition technologies. With excellent optical and electronic properties, SnS Pellets are ideal for applications such as thin-film solar cells, thermoelectric devices, and photodetectors. These pellets are integral to research and development in advanced electronic materials and energy-efficient devices.
Key Features
- High purity (≥99.99%).
- Outstanding semiconducting properties with a direct bandgap.
- Suitable for thin-film deposition methods like PVD and CVD.
- Excellent stability under high-temperature and chemical conditions.
- Customizable sizes and packaging options available.
Technical Specifications
â‘ Chemical Composition
- Tin Sulfide (SnS) Content: ≥99.99%.
- Trace Impurities: Provided upon request.
â‘¡ Physical Properties
- Appearance: Gray to black pellets.
- Density: ~5.22 g/cm³.
- Melting Point: ~882°C.
â‘¢ Pellet Size
- Standard Sizes: 1-3 mm, 3-5 mm.
- Custom sizes available upon request.
Applications
- Thin-Film Solar Cells: SnS is a promising material for environmentally friendly and cost-effective solar cell production due to its excellent absorption properties.
- Thermoelectric Devices: Used in thermoelectric applications for converting waste heat into electricity efficiently.
- Photodetectors and Sensors: Ideal for optical sensors and photodetectors due to its high optical sensitivity.
- Thin-Film Deposition: Suitable for physical vapor deposition (PVD) and chemical vapor deposition (CVD) processes in electronics manufacturing.
- Research and Development: Widely employed in studies on semiconducting materials and energy-efficient electronic systems.
Product Advantages
- Environmentally Friendly Material: Lead-free and cadmium-free, making it ideal for sustainable applications.
- High Purity: Ensures reliable performance in advanced applications.
- Versatile Applications: Suitable for energy conversion, optoelectronics, and thin-film technology.
- Customizable Options: Pellet sizes and packaging tailored to customer requirements.
- Durable: Stable under a wide range of operational conditions.
Packaging and Storage
â‘ Packaging
- Vacuum-sealed, moisture-resistant containers.
- Custom packaging available upon request.
â‘¡ Storage
- Store in a cool, dry environment.
- Keep sealed to prevent oxidation or contamination.
Quality Certifications
- ISO 9001 Certified Quality Management System.
- RoHS Compliance.
- Certificates of Analysis (COA) and Material Safety Data Sheets (MSDS) available upon request.
For further details or to request a quote, please contact us. Our team is dedicated to providing high-quality materials and tailored solutions for your specific requirements.
