SnS2 (Tin Disulfide) Pellets Granules Evaporation Materials

Description

Material	Tin Disulfide (SnS₂)
Purity	99.9% – 99.9999% / 3N 3N5 4N 4N5 5N 5N5 6N
Shape	Pellets / Granules / Particles / Pieces
Size	can be customized (contact us)
Package	vacuum bag or customer’s request
Supply Ability	1000kg per month
Lead Time	Qty: 1-100, Time: 3-10 days Qty: >100, Time: to be negotiated



SnS₂ Pellets (Tin Disulfide Pellets) are high-quality semiconductor materials primarily used in optoelectronics, energy storage, and thin-film deposition. Known for their excellent electronic and optical properties, SnS₂ Pellets are ideal for applications such as photovoltaic cells, photodetectors, and energy-efficient devices. These pellets are widely used in research and development for advanced materials and electronic applications.

Key Features

• High purity (≥99.99%).
• Semiconductor material with strong optical and electronic properties.
• Excellent performance in thin-film deposition techniques like PVD and CVD.
• Stable under high-temperature and chemical conditions.
• Custom sizes and packaging available.

Technical Specifications

① Chemical Composition

• Tin Disulfide (SnS₂) Content: ≥99.99%.
• Trace Impurities: Available upon request.

② Physical Properties

• Appearance: Yellow to light brown pellets.
• Density: ~4.37 g/cm³.
• Melting Point: ~1200°C.

③ Pellet Size

• Standard Sizes: 1-3 mm, 3-5 mm.
• Custom sizes available upon request.

Applications

• Photovoltaic Cells: SnS₂ is widely used in the fabrication of thin-film solar cells, contributing to energy-efficient solar power generation.
• Photodetectors and Sensors: Ideal for use in photodetectors and sensors in optoelectronic systems due to its excellent light-absorption properties.
• Thin-Film Deposition: Utilized in thin-film deposition methods for manufacturing high-performance electronic devices.
• Energy Storage Devices: Employed in energy storage devices like supercapacitors and batteries due to its high conductivity and stability.
• Research and Development: A valuable material for research in semiconductor devices, optoelectronic applications, and nanomaterials.

Product Advantages

• Semiconducting Properties: Ideal for use in photovoltaic, optoelectronic, and sensor applications.
• Excellent Optical Properties: Strong absorption and light transmission in specific wavelengths.
• High Purity: Ensures consistent and reliable performance.
• Customizable Options: Available in various sizes and packaging to meet specific needs.
• Durability: Stable under high-temperature and chemical environments.

Packaging and Storage

① Packaging

• Vacuum-sealed, moisture-proof containers.
• Custom packaging options available.

② Storage

• Store in a dry, cool, and well-ventilated area.
• Keep airtight to avoid moisture contamination and preserve the material’s quality.

Quality Certifications

• ISO 9001 Certified Quality Management System.
• RoHS Compliance.
• Certificate of Analysis (COA) and Material Safety Data Sheet (MSDS) available upon request.

For more information or to request a quote, please contact us. Our expert team is ready to assist with your specific material requirements and provide tailored solutions.
