Zn3Sb2 (Zinc Antimony) Sputtering Targets
- Thermoelectric Properties: Zn₃Sb₂ is known for its high thermoelectric efficiency, making it an excellent material for energy conversion applications.
- High Purity: Available in various purity grades, ensuring the production of high-quality thin films.
- Stable Deposition: Consistent film quality and performance, ideal for advanced manufacturing processes.
- Durability: Offers excellent thermal stability, reducing the risk of material degradation during deposition and application.
- Wide Application Range: Suitable for a variety of industries, including semiconductor, energy, and sensing technologies.
Custom products or bulk orders, please contact us for competitive pricing!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
| Material | Zinc Antimony (Zn₃Sb₂) |
| Purity | 99.9% – 99.9999% / 3N 3N5 4N 4N5 5N 5N5 6N |
| Shape | disc, plate, sheet, rod, customized |
| Size | can be customized (contact us) |
| Package | vacuum bag or customer’s request |
| Place of Origin | China |
| MOQ | 1pcs |
| Supply Ability | 10000pcs per month |
| Lead Time | Qty: 1-100, Time: 3-10 days
Qty: >100, Time: to be negotiated |
Zn₃Sb₂ (Zinc Antimony) sputtering targets are advanced materials used for thin-film deposition in various high-performance applications. This compound exhibits unique thermoelectric properties, making it ideal for use in thermoelectric devices, energy harvesting systems, and other electronics. Zn₃Sb₂ sputtering targets are also employed in the fabrication of semiconductor devices, sensors, and optoelectronic components. The material offers excellent thermal stability, high conductivity, and consistent film quality during deposition processes, making it an essential choice for researchers and manufacturers in multiple industries.
Key Applications
- Thermoelectric Devices: Used in the fabrication of materials for thermoelectric power generation and cooling.
- Semiconductor Industry: Ideal for thin-film deposition in semiconductor devices.
- Energy Harvesting: Employed in thermoelectric generators to convert waste heat into electrical energy.
- Optoelectronics: Used in the production of optoelectronic devices and sensors.
- Sensing Technology: Involved in the creation of thermistors and other temperature-sensitive devices.
Features and Benefits
- Thermoelectric Properties: Zn₃Sb₂ is known for its high thermoelectric efficiency, making it an excellent material for energy conversion applications.
- High Purity: Available in various purity grades, ensuring the production of high-quality thin films.
- Stable Deposition: Consistent film quality and performance, ideal for advanced manufacturing processes.
- Durability: Offers excellent thermal stability, reducing the risk of material degradation during deposition and application.
- Wide Application Range: Suitable for a variety of industries, including semiconductor, energy, and sensing technologies.
Specifications
- Purity: 99.9%, 99.99%, 99.999%, 99.9999% grades available.
- Diameter: Custom diameters to fit various sputtering systems.
- Thickness: Available in different thicknesses for specific deposition needs.
- Form: Disc, circular, and custom shapes upon request.
- Applications: Ideal for use in sputtering systems for thermoelectric and optoelectronic applications.
Customization Options
- Custom sizes, shapes, and purity levels tailored to your specific requirements.
- Target backing materials can be customized to fit specific sputtering systems.
- Custom packaging and shipping options are available for bulk orders.
For more information or to request a quote for Zn₃Sb₂ sputtering targets, please contact us. Our team is here to provide expert assistance and ensure you get the perfect target for your thin-film deposition applications.
